Valves Supplied

Size:       2”, 3”, 4”, and 6” ANSI 600 Class
Body Material:    WCC Carbon Steel
Internals:    Carbon Steel – Electrolysis Nickel Plated
Trim:    Teflon Seated – NACE Trim
Port:    Full Port
Connections:    Raised Face Flanged

Service Conditions

Media:    Sour Natural Gas – some entrained sand
Manual / Actuated:    Pneumatic Spring Close Actuated
Temperature:    Ambient
Orientation (Stem: Horizontal, Vertical, Other):    Horizontal
Pressure:    1200 psig

Application/Service Conditions

Initial valve installation was a manual block valve application in a natural gas gathering system immediately off of a natural gas well. Some of these well streams include sour / corrosive media requiring materials of construction suitable for NACE service. The customer uses multiple valve sizes in manual and automated configurations in these applications. The customer determined, after initial test / evaluation, the internal stationary Core protected the seats from potential minimizing damage from higher velocities and services that could possibly include entrained solids.

The first Hemiwedge® valves were tested in March 2008. Eventually the Hemiwedge® valves were installed in more demanding, higher flow applications including produced natural gas service including entrained sand. In the case of the ESD (Emergency Shut Down) applications, the valve is required to close and seal bubble tight in emergency conditions to isolate flow from well into gathering systems. With the internal Core of the Hemiwedge® valve providing better protection of the seat/seals, and the significantly reduced hydrodynamic torque, the Hemiwedge® valve design provides the operation dependability and reliability demanded for ESD services.
